Vacuum Tray Dryer Manufacturer in Maharashtra

Mecha Engineering Pvt. Ltd. designs and fabricates vacuum tray dryers at its own works at Village Meharbani on Behat Road, Saharanpur, Uttar Pradesh. The company was set up in 2022 and supplies drying, extraction, blending and process equipment to pharmaceutical, herbal, chemical, food and cosmetic units across Maharashtra, the rest of India and export markets. You buy from the fabricator, not from a trading house.

Standard models run at 6, 12, 24, 48 and 96 trays, and non-standard tray counts are built where a batch size falls between two models. Tell us the wet cake weight you want to dry in one batch and the thickness you can spread on a tray, and we work backwards to the tray count, shelf area and chamber size.

Two ways. Heat comes in by contact through the hollow shelves rather than by hot air blowing across the product, and the vacuum inside the chamber lowers the boiling point of the moisture so it leaves at a much lower temperature. Together they let a delicate herbal extract or API intermediate dry fully without the thermal degradation an air oven would cause.

The standard build uses SS 304 for the chamber interior, shelves and trays. SS 316 and SS 316L are used where the product or solvent is corrosive, or where a pharma audit requires it. Mill test certificates for every plate and pipe are issued in your company name and handed over with the dryer along with the GA drawing and test report.

If your cake is only water wet, a condenser is often skipped to save cost. If it carries ethanol, methanol, IPA, acetone or any other solvent, order the condenser, receiver, cooling coil and vacuum trap. It recovers the solvent as condensate, keeps vapour out of the vacuum pump and stops you venting solvent into the shed.

Steam and hot water are the usual choice and cover most Maharashtra installations, since almost every MIDC unit already has a boiler on the floor. Thermic fluid is used where a higher shelf temperature is needed, and electric heating is offered on 6 and 12 tray lab models. Tell us the utility you already have and we build the shelf circuit around it.

Erection, utility tie-in, vacuum pump and condenser piping, leak check, first product batch and operator training at your Maharashtra site are part of the supply scope. Our commissioning engineers travel from Saharanpur and stay on site until the first batch is signed off, so the visit is planned as one continuous trip rather than repeated short calls.

Standard handover covers the general arrangement drawing, material of construction certificates, vacuum and leak test reports, weld and polish records, the operating and maintenance manual and a spare parts list. DQ, IQ and OQ protocols, along with a validation document set, are prepared on request for GMP and export buyers.

Standard 6 to 48 tray models are built in 4 to 8 weeks from order confirmation and a 96 tray double door or fully automated unit takes 8 to 10 weeks. Road transit from Saharanpur to Maharashtra adds roughly 3 to 4 days. Freight is quoted at actual cost, and for larger chambers we arrange the trailer, route survey and unloading crane along with the dispatch.

Call +91-9084351006 or +91-7500378000, send a WhatsApp message, or email info@mechaengg.com with four details: the product you are drying, the wet cake weight per batch, the solvent or moisture involved and the utility available on your floor. A specification sheet and price come back within one working day.
