Verified Material Grade
SS 316 or SS 316L on every product contact surface, backed by mill test certificates issued in your company name.
Nicotine Extraction Plant Manufacturer in Uttarakhand
Mecha Engineering designs and fabricates nicotine extraction plants at its own works in Saharanpur, about two hours from Haridwar, and installs them at pharmaceutical, nutraceutical and chemical units across Uttarakhand. Extractors from 100 litres to 10,000 litres, closed handling throughout, built around the waste stream you bring in.
- SS 316 contact parts
- 100 L to 10,000 L extractors
- Closed handling and ventilation
- Solvent and water recovery built in
- Erection and commissioning across Uttarakhand
100 LSmallest pilot extractor
10 kLLargest single extractor
SS 316Contact parts standard
13Districts served
Nicotine Extraction Plant in Uttarakhand
Uttarakhand's case is a pharmaceutical one. Haridwar, Bhagwanpur, Roorkee, Selaqui and the SIDCUL estates at Rudrapur, Sitarganj and Kashipur hold a dense pharmaceutical, nutraceutical and ayurvedic base, and nicotine for replacement therapy is a pharmaceutical input before it is anything else. The feedstock comes in under contract from processing units in the tobacco growing states, which makes inbound logistics part of the project rather than an afterthought. Haridwar sits about two hours from our works.
Buyers searching for a nicotine extraction plant manufacturer in Uttarakhand are choosing between a trader and a fabricator. Mecha Engineering is the fabricator, and the nearest one to the Haridwar belt. We size the line around the waste you bring in, its assay and the product grade your buyer specifies, then build, assemble and trial it at our own works in Saharanpur before a short road run to your site.
- Engineers who travel. Erection, commissioning, the first trial batch and operator training happen on your floor in Uttarakhand, not over a phone call.
- Closed from extractor to drum. Nicotine concentrate is acutely toxic, so transfers are piped and pumped rather than poured, sampling points are closed, and the handling area is ventilated and bunded.
- Audit ready paperwork. MOC certificates, GA drawings, P and ID, weld and polish records and IQ or OQ documents go with the plant, in the form a regulator or an export buyer asks for.
- Spares held in stock. Gaskets, seals, strainers, filter media, sight glasses and vacuum fittings are kept at the works and dispatched to Uttarakhand the same week you ask.
What you get with every plant
Four Commitments Behind Each Uttarakhand Installation
These are the points a Uttarakhand buyer checks before releasing a purchase order, so we put them in writing rather than in a brochure line.
Trial Before Dispatch
Water run, pressure hold and leak test at our Saharanpur shop. Send a feedstock sample and we run a recovery trial on the pilot skid before the commercial line is built.
Installation by Our Team
Erection, piping tie-in, utility connection, commissioning and operator training at your Uttarakhand site, covered in the supply scope.
Direct Manufacturer Pricing
You buy from the fabricator, not a trading house. No dealer margin, and any design change is quoted against actual material and labour.
Build features
Features of Mecha Engineering Nicotine Extraction Plants:
Every feature below protects one of three things: the assay your buyer pays for, the people on your floor, or the cost of the medium you put through the plant.
01
Closed Handling Throughout
The concentrate never sits in an open vessel. Transfers run through piped, pumped lines to closed receivers and drums, sampling is through closed points, and the handling area is ventilated and bunded with eyewash and shower stations in reach.
02
Staged Counter-Current Extraction
Staged contact between the prepared feed and the extraction medium recovers more alkaloid per batch while putting less liquid through the evaporator afterwards, which is where most of the running cost sits.
03
Vacuum Concentration
Concentration under vacuum holds the temperature down, so the assay is protected and steam consumption per batch drops against an atmospheric boil off.
04
Purification Sized to Your Grade
The purification section is built for the specification your buyer actually writes, with in-process sampling points at each stage so a batch is checked on the way through rather than argued about afterwards.
05
Medium Recovered, Not Vented
Shell and tube condensers, receivers and a vent condenser return the extraction medium to the next batch. On an imported solvent that recovery is the difference between a viable cost per kilo and a bad one.
06
Spent Biomass and Effluent Planned For
De-nicotinised residue is dewatered and discharged in a form you can compost, briquette or feed to a boiler, and the liquid effluent load is designed down rather than left for your treatment plant to absorb.
Sections we supply
Nicotine Extraction Plant Sections for Uttarakhand Processors:
Take the complete line, or the one section that is holding your existing plant back. Send your feedstock analysis and we will tell you which of these you need.
Feedstock Preparation Section
Screening, de-dusting, foreign matter removal, moisture conditioning, milling and closed conveying, so what reaches the extractor is consistent batch after batch.
Batch Extraction Battery
Jacketed SS 316 extractors from 100 litres to 10,000 litres with agitation, strainer and drain, plumbed as a battery so one vessel charges while another is extracting.
Counter-Current Extraction Line
Staged contact for continuous operation, used where the daily feedstock quantity justifies running through the shift rather than in isolated batches.
Filtration and Clarification Section
Strainers, filter press or sparkler filter, decanter and centrifuge options to take the fines out of the liquor before it reaches the evaporator.
Concentration and Purification Section
Vacuum evaporator or falling film unit, condensers, receivers and a purification section sized to the grade you supply, with closed transfer to the storage tanks.
Pilot and Development Plant
A 100 to 500 litre skid for feedstock trials, assay work and yield studies before a commercial line is committed. The usual first step for a new entrant.
Technical data
Nicotine Extraction Plant Specifications:
Standard build for a batch extraction line with concentration and purification. Every line below is changed to order, so treat this as the starting point for your enquiry rather than a fixed model list.
| Parameter | Standard offering | Options on request |
|---|---|---|
| Plant Type | Batch extraction battery with concentration and purification | Counter-current continuous line, pilot scale skid |
| Extractor Capacity | 100, 250, 500, 1000, 2000 and 5000 litres | Up to 10,000 litres, and multi-vessel batteries |
| Feedstock Accepted | Tobacco dust, fines, scrap leaf, stem and midrib | Floor sweepings, low grade leaf and sheet trim, by agreement |
| Material of Construction | SS 316 on all product contact parts | SS 316L, special alloy where the medium demands it |
| Internal Finish | 220 grit mirror polish on contact surfaces | Electropolished finish for pharmaceutical grade duty |
| Heating Arrangement | Limpet coil or dimple jacket, steam or hot water | Thermic fluid, electric heating on the pilot skid |
| Agitation | Anchor or turbine stirrer with geared motor | VFD speed control, bottom entry drive |
| Filtration | Strainer at the extractor outlet plus filter press | Sparkler filter, decanter, centrifuge, polishing filter |
| Concentration | Vacuum evaporator with condenser and receiver | Falling film or multi-effect unit for larger duty |
| Purification | Purification section sized to your product grade | Additional stages where a higher assay is specified |
| Medium Recovery | Shell and tube condensers, receiver, vent condenser | Chilled water condenser, scrubber on the vent line |
| Handling and Safety | Closed transfer lines, ventilated and bunded area, eyewash and shower points, PPE stations | Gas detection, flameproof fittings where a flammable medium is used, nitrogen purging |
| Residue and Effluent | Dewatering of spent biomass, effluent collection sump | Briquetting or boiler feed tie-in, effluent treatment plant interface |
| Control System | Local panel with temperature, vacuum and level indication | PLC with HMI, recipe storage, batch report, SCADA link |
| Power Supply | 415 V, 3 phase, 50 Hz | Supply voltage changed to suit another site |
| Documentation | GA drawing, P and ID, MOC certificates, test report, manual | DQ, IQ, OQ protocols, third party inspection, licensing support pack |
Scroll the table sideways on a mobile screen. Send your feedstock type, the tonnes you handle per month and the product grade your buyer specifies, and we will fill this sheet in against your process.
Choosing a configuration
Which Feedstock Fits your Uttarakhand Plant?
The feedstock decides the preparation section and the extractor, not the other way around. This is the shortlist we work through on the first call.
| Feedstock | Preparation needed | Section that changes | Typical source in Uttarakhand |
|---|---|---|---|
| Tobacco Dust and Fines | Screening and de-dusting only | Dust handling and extraction | Contract supply in from the growing states |
| Stem and Midrib | Milling and moisture conditioning | Preparation section | Threshing plants under contract supply |
| Scrap and Offcut Leaf | Cutting and conditioning | Preparation and extraction | Contract supply into the SIDCUL estates |
| Floor Sweepings and Rejects | Screening to remove foreign matter | Preparation and filtration | Any tobacco processing unit supplying Uttarakhand |
| Low Grade or Unsold Leaf | Drying and cutting | Preparation and extraction | Trade stockists supplying the pharmaceutical belt |
| Reconstituted Sheet Trim | Milling only | Preparation section | Sheet and filler plants supplying the trade |
Not sure which row you belong to? Send a feedstock sample with a recent assay report and we will confirm the configuration along with an indicative recovery figure.
How the plant runs
The Extraction Cycle, Step by Step
Six stages from tobacco waste to a drummed product. Your operator sees the same sequence on every batch, which is what keeps the assay consistent and the records defensible.
01
Intake and Preparation
Incoming waste is weighed, screened for foreign matter, conditioned for moisture and milled to a consistent size, then conveyed to the extractor in a closed system.
02
Charging and Extraction
Measured feed and extraction medium are charged to the jacketed extractor. Agitation, temperature and contact time run to the recipe your process team sets.
03
Separation of the Liquor
Liquor is drained through the strainer and clarified in the filtration section. Spent biomass is discharged for dewatering and onward disposal or reuse.
04
Concentration Under Vacuum
The liquor is concentrated in the vacuum evaporator. Vapour is condensed and the medium returns to the receiver for the next batch rather than going to effluent.
05
Purification to Grade
The concentrate passes through the purification section until it meets the specification your buyer has written, with samples drawn at each stage for in-process checks.
06
Closed Transfer and Storage
Product is pumped through closed lines into drums or tanks held in a ventilated, bunded store, with batch records, weights and assay results filed against each container.
Where these plants are used
Application Areas of Nicotine Extraction Plants:
Pharmaceutical Grade Nicotine
Producers supplying nicotine for nicotine replacement therapy and other pharmaceutical use, where SS 316 contact parts, a polished finish and a complete document set are specified before the first quotation is compared. The pharmaceutical and nutraceutical plants of Haridwar, Selaqui, Dehradun, Rudrapur and Kashipur are the clearest buyer base of any state we supply.
Supply to Regulated Export Markets
Producers shipping nicotine solutions and salts to buyers whose own regulator audits the process, which is why documentation and in-process records are specified alongside the equipment.
Tobacco Processing Waste Valorisation
Units taking in tobacco processing waste under contract and turning it into a saleable stream rather than a disposal cost, which is how most Uttarakhand projects are structured.
Analytical and Research Material
Laboratories and institutions needing small, well characterised quantities, usually served by the pilot skid rather than a commercial line.
Industrial and Agrochemical Intermediates
Intermediate supply into markets where nicotine based formulations remain permitted, which varies by country and is worth confirming with your buyer before you size the plant.
Contract and Toll Processors
Units processing another company's tobacco waste under contract, who are judged on recovery, turnaround and the completeness of the batch record.
Supply and service network
Our Nicotine Extraction Plant Network Across Uttarakhand
Dispatch, erection and site service run out of our Saharanpur works. These are the districts we work in most often.
- Haridwar
- Dehradun
- Udham Singh Nagar (Rudrapur)
- Nainital (Haldwani)
- Pauri Garhwal
- Tehri Garhwal
- Almora
- Bageshwar
- Chamoli
- Champawat
- Pithoragarh
- Rudraprayag
- Uttarkashi
District not on the list? The list is only where we see the most enquiries. Site visits, erection and after-sales service cover all 13 districts of Uttarakhand, and the rest of India.
Equipment that runs beside it
Related Machines Supplied Across Uttarakhand
A nicotine extraction line rarely arrives alone. These are the machines buyers most often order in the same enquiry.
Questions we are asked
Nicotine Extraction Plants in Uttarakhand: FAQs
Straight answers to what Uttarakhand buyers ask before and after a site visit.
Who manufactures nicotine extraction plants in Uttarakhand?
Mecha Engineering Pvt. Ltd. designs and fabricates nicotine extraction plants at its own works at Village Meharbani on Behat Road, Saharanpur, roughly two hours from Haridwar. The company was set up in 2022 and supplies extraction, distillation, filtration and drying plants to pharmaceutical, nutraceutical, herbal and chemical units from Haridwar and Roorkee to Dehradun, Rudrapur and Kashipur.
What capacity range can you supply?
Extractors run from 100 litres for pilot and development work up to 10,000 litres for commercial lines, and multi-vessel batteries are built where counter-current or continuous operation is needed. Tell us the tonnes of tobacco waste you handle a month and the assay of that waste, and we work backwards to the extractor size and the number of batches per shift.
Which tobacco feedstock can the plant process?
Tobacco dust and fines, scrap and offcut leaf, stem and midrib from threshing, floor sweepings after screening, low grade or unsold leaf, and reconstituted sheet trim. What changes between them is the preparation section rather than the extractor, which is why we ask for a feedstock sample and a recent assay report before quoting.
What material of construction do you use, and can I get certificates?
SS 316 is standard on every product contact surface, with SS 316L and special alloys where the medium demands it, and a 220 grit mirror polish as standard with electropolishing available for pharmaceutical grade duty. Mill test certificates for every plate and pipe are issued in your company name and handed over with the GA drawing, the P and ID and the test report.
How is the nicotine concentrate handled safely?
Nicotine concentrate is acutely toxic, and the plant is designed around that from the first drawing rather than afterwards. Transfers run through closed, piped and pumped lines into closed receivers and drums, sampling is through closed points, and the handling and storage area is ventilated and bunded with eyewash and shower stations, PPE storage and spill containment laid out alongside the equipment. We supply the engineering; the operating procedures and the training for your team sit with you and your safety officer.
Do we need licences to run a nicotine extraction plant?
Yes. Nicotine is a regulated substance and the approvals that apply depend on your state, your feedstock source and your end market. Expect factory and pollution control approvals for the plant itself, storage approvals for the concentrate, and separate requirements on the product side depending on who you sell to and where. Confirm the position with your regulator and your buyer before you commit to a capacity, because the end market you are allowed to serve is what decides the purification section you need.
What happens to the spent tobacco biomass and the effluent?
Spent biomass leaves the extractor de-nicotinised and is dewatered, after which most plants compost it, briquette it or feed it to a boiler rather than paying to dump it. The liquid effluent load is kept down by recovering the extraction medium instead of discharging it, and we design the collection sump and the interface to your effluent treatment plant along with the rest of the line.
Can you supply only one section instead of a full plant?
Yes, and it is common. Typical jobs are adding a proper preparation section ahead of an existing extractor, putting in vacuum concentration to replace an atmospheric boil off, adding a filtration stage before the evaporator, upgrading the medium recovery so less goes to effluent, and fitting closed transfer and a bunded store to a plant that handles concentrate in the open today. Send photographs, your current layout and a nameplate reading to start.
Is installation and commissioning included for Uttarakhand sites?
Erection, piping tie-in, utility connection, the water trial, the first feedstock batch and operator training at your Uttarakhand site are part of the supply scope. Dispatch is from Saharanpur, so our erection team reaches a Uttarakhand site on a direct road run.
How long does delivery take, and what about freight inside Uttarakhand?
A pilot or small batch plant is generally ready in 10 to 14 weeks from order confirmation. A commercial line with concentration and purification takes 18 to 26 weeks depending on capacity and the degree of automation, with erection running alongside your civil work. Freight inside Uttarakhand is quoted at actual cost, and for larger vessels we arrange the trailer, route survey and unloading crane along with the dispatch.
How do I get a price for my plant?
Call +91-9084351006 or +91-7500378000, send a WhatsApp message, or email info@mechaengg.com with four details: the feedstock you will process, the tonnes per month you want to handle, a recent assay of that feedstock and the product grade your buyer specifies. A specification sheet, layout and price come back within one working day.
Talk to the specialist
Get Your Nicotine Extraction Plant Quoted This Week
Share the feedstock, the tonnes you handle per month and the product grade your buyer specifies. Our Saharanpur engineering team returns a specification sheet, plant layout and price so you can compare on paper rather than on promises.
